Air Brake Hose Assembly 0.38" ID 72.00" Fixed x Swivel 3/8" Fitting Rubber - 177.7272

Air Brake Hose Assembly 0.38" ID 72.00" Fixed x Swivel 3/8" Fitting Rubber - 177.7272

Part#: AAA4107272

Features and Benefits

Air brake hose assembly for male pipe x male pipe connections across extended truck chassis routing
Flexible reinforced rubber construction in black for durability in under-truck operating conditions
Inner diameter at 3/8" for reliable compressed air flow between brake valves and actuators
Crimped brass fittings on both ends for permanent, leak-resistant joint integrity at full pressure
End 1 fixed and End 2 swivel at 3/8" pipe for alignment versatility during chassis installation
Overall length at 72" for maximum reach across long-wheelbase tractor and trailer brake circuits

Select Alternative Part #

177.7272

Warranty

Up to 3 years warranty

Please contact customer service to know more details

SPECIFICATIONS
INTERCHANGE
APPLICATION
DESCRIPTION

Type	Air Brake Hose Assembly
Hose Style	Flexible Straight Hose
Inner Diameter	0.38 in.
Overall Length	72.00 in.
Material	Rubber
Color	Black
Construction	Flexible Reinforced Rubber
Connection Size	3/8 in.
Pipe Size	3/8 in.
Connection Type	Male Pipe x Male Pipe
End 1	3/8 in. Pipe
End 2	3/8 in. Pipe
End 1 Style	Fixed
End 2 Style	Swivel
Fitting Configuration	Fixed x Swivel
Number of Connections	2.00
Fitting Material	Brass / Metal
End Attachment	Crimped
Ferrule Type	Metal Crimp Sleeve
Flexibility	Flexible
Weight	1.20 lbs.

Interchange

146072
16672
453272
ATM1777272
E858072BK
R95550372BK

No data found.

The Air Brake Hose Assembly delivers dependable Heavy Duty performance across demanding commercial vehicle applications. Constructed from reinforced rubber with a 0.38 in. inner diameter, the flexible straight design spans 72.00 in. to accommodate varied routing needs. Male pipe connections on both ends feature a fixed-to-swivel configuration secured by crimped brass fittings.
