Male Elbow Fitting 5/32" 90° Brass 1/8" NPT - 177.13B1525A-C
Part#: AAA40713B1525A-C
Features and Benefits
- Product type of brass plc male elbow 5/32 x 1/8" NPT for confirmed system compatibility
- Material of brass for durable, long-lasting performance
- Thread size of 5/32" for confirmed fitment accuracy
- Pipe end sized at 1/8" for confirmed coupling compatibility
- DOT approved included for accurate service performance
- Weight of 0.30 lbs. for a complete, ready-to-install package
Select Alternative Part #
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Product Type | Brass PLC Male Elbow 5/32 x 1/8 in. NPT |
|---|---|
| Thread Size 1 | 5/32 in. |
| Thread Size 2 | 1/8 in. NPT |
| Material | Brass |
| Type | PLC Male Elbow |
| Tube End | 5/32 in. |
| Pipe End | 1/8 in. |
| Angle | 90 Deg. |
| Weight | 0.30 lbs. |
| Dimensions | 1.00 in. x 0.90 in. x 0.40 in. |
| Connection Type | Male Elbow |
| Thread Size | 1/8 in. NPT |
| Tube Size | 5/32 in. |
| Tube Outer Diameter | 5/32 in. |
| Pipe Thread | 1/8 in. NPT |
| DOT Approved | Yes |
| Fitting Type | Push Lock Connect |
| Pipe Size | 1/8 in. |
| Tube | 5/32 in. |
| Interchange |
|---|
| #6661HDA |
| 17713B1525A |
| 1869X25 |
| 269PMT5322 |
| 889626746789 |
| AQ69DOT532X2 |
| PL131525A |
| S269PMTNS5322 |
No data found.
The Brass Push-In Elbow joins 5/32" and 1/8" lines at a 90-degree bend, engineered for Heavy Duty commercial air and fluid systems. Machined from brass, the fitting resists corrosion and repeated thermal cycling in daily fleet use. The piece ships pre-packaged, ready for prompt setup.
