Automatic Slack Adjuster Stroke 28 Spline 1.50" - 139.2835
Part#: AAA6011392835
Features and Benefits
- Type 1 stroke sensing slack adjuster with blue piston for accurate installation identification
- Blue piston color provides clear visual distinction from Type 2 and yellow piston variants
- Stroke sensing mechanism tracks push rod travel distance to deliver timely brake adjustment
- Arm length provides consistent lever action for push rod actuation on compatible chamber setups
- Spline engagement ensures reliable torque transfer to standard commercial brake camshafts
- Straight clevis with compatible chamber size for reliable Type 1 blue piston brake fitment
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Weight | 6.90 |
|---|---|
| Type | Type 1 |
| Piston | Blue Piston |
| Arm Length | 5.50 in. |
| Slack Spline Diameter | 1.50 in. |
| Slack Spline Count | 28 |
| Sensing Type | Stroke |
| Chamber Sizes | 30 |
| Clevis Thread Diameter | 0.625 in. |
| Clevis Threads per inch | 18 |
| Maximum Torque Rating | More than 45 inch pounds |
| Interchange |
|---|
| 05563 |
| 1694309C91 |
| 764015073 |
| 8235R802463 |
| 85102944 |
| A293275U593 |
| A293275U593S |
| A433275Z1144S |
| A443275Z1144 |
| A573275U593S |
| A703275Z1144S |
| ACCAS1140 |
| ATIR802463 |
| CS56040 |
| CS56040M1D |
| E11420 |
| E6994A |
| EUE11420 |
| GHAS1140 |
| GUNAS1140 |
| HDXCS56040 |
| R802460 |
| R802463 |
| R802463RI |
| R803050 |
| RIR802463 |
| TDAR802463 |
| ZBRAS1040 |
| ZBRAS1140 |
| ZZCS56040 |
The Slack Adjuster is a Type 1 stroke-sensing design with a blue piston and 5.5" arm, built for automatic adjustment on Heavy Duty commercial vehicle axles. Featuring a straight clevis configuration, the component delivers consistent stopping performance and dependable actuation across a wide range of transport platforms.
