Union Connector DOT Push-to-Connect Brass 1/4 150 psi - 620400C
Part#: AAA717620400C
Features and Benefits
- Straight union fitting in push-to-connect DOT style for 1/4 in in-line air brake connection
- Push-to-connect connection type for tool-free tubing insertion at both DOT union ports
- Brass body material for durable, corrosion-resistant fitting performance in air brake service
- Nitrile (NBR) seal material for reliable sealing performance in DOT air brake system media
- Pressure rating of 150 psi for reliable DOT air brake system operating pressure performance
- Temperature range of -40 to 200 °F for broad climate and DOT air brake service temperature coverage
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Body Material | Brass |
|---|---|
| Connection Size | 0.25 in. |
| Connection Size 1 | 0.25 in. |
| Connection Size 2 | 0.25 in. |
| Connection Type | Push-to-Connect |
| Fitting Style | Straight Union |
| Pressure Rating | 150 psi |
| Seal Material | Nitrile (NBR/Buna-N) |
| Temperature Rating | -40 to 200 °F |
| Interchange |
|---|
| 016640 |
| 16640 |
| 262PPCDOT4 |
| 32PTC4 |
| 501082 |
| 98702 |
| CDOT14624 |
| KV2H0700 |
| QL13624 |
| S762PMT4 |
No data found.
The Union Connector is a push-to-connect straight union fitting with a brass body and 1/4" connection size, engineered for rapid, tool-free tube joining in Heavy Duty commercial vehicle air brake systems. The component delivers consistent sealing performance and reliable service life across pneumatic plumbing configurations.
