Union Connector DOT Push-to-Connect Brass 1/2 145 psi - 620800C
Part#: AAA717620800C
Features and Benefits
- Straight union fitting in push-to-connect DOT style for 1/2 in in-line air brake connection
- Push-to-connect connection type for tool-free tubing insertion at both DOT union ports
- PBT and brass body construction for lightweight polymer-plus-metal corrosion-resistant performance
- Compatible with SAE J844 Type A/B air brake tubing for confirmed DOT standard tubing fitment
- Nitrile (NBR) seal for reliable sealing performance in DOT air brake system pressure media
- Pressure rating of 145 psi for DOT air brake system operating pressure performance in service
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Body Material | PBT/Brass |
|---|---|
| Compatible Tubing | SAE J844 air brake tubing (SAE J844 Type A/B) |
| Connection Size | 0.50 in. |
| Connection Size 1 | 0.50 in. |
| Connection Size 2 | 0.50 in. |
| Connection Type | Push-to-Connect |
| Fitting Style | Straight Union |
| Pressure Rating | 145 psi |
| Seal Material | Nitrile (NBR/Buna-N) |
| Temperature Rating | 140 °F |
| Interchange |
|---|
| 016680 |
| 16680 |
| 262PPCDOT8 |
| 32PTC8 |
| 501082 |
| 98704 |
| CDOT14628 |
| KV2H1300 |
| QL13628 |
| S762PMT8 |
No data found.
The Union Connector is a push-to-connect straight union fitting with a composite body and 1/2" connection size, engineered for rapid, tool-free tube joining in Heavy Duty commercial vehicle air brake systems. The component delivers consistent sealing performance and reliable service life across pneumatic plumbing configurations.
