Coolant Hose 2.50" Standard / Customizable Reinforced Silicone Up To 75 psi - 561.0925

Coolant Hose 2.50" Standard / Customizable Reinforced Silicone Up To 75 psi - 561.0925

Part#: AAA4370925

Features and Benefits

Material of reinforced silicone construction for the product body
Length of standard / customizable or 36" for correct fitment span
Inner diameter of 2.5" for correct fitment engagement
Wall thickness of 4 to 0.24" for the product material gauge
Reinforcement of polyester / fabric ply for the hose pressure-handling construction
Ply count of 4 for the hose wall construction

Select Alternative Part #

561.0925

Warranty

Up to 3 years warranty

Please contact customer service to know more details

SPECIFICATIONS
INTERCHANGE
APPLICATION
DESCRIPTION

Chemical & Oil Resistance	Heat, Ozone, Uv, Coolant
Flexibility	High Flexibility
Industry Standard / Compliance	SAE J20 / OEM Standards
Inner Diameter	2.50 in.
Length	Standard / Customizable
Length	36.00 in.
Material	Reinforced Silicone
Material	Silicone
Max Operating Pressure	Up To 75 PSI
Mechanical Durability	3X Working Pressure
Number of Plies	4.00
Operating Temperature Range	60° F to +350° F
Reinforcement	Polyester / Fabric Ply
Surface Finish	Smooth Inner / Matte Outer
Wall Thickness	4–6 Mm

Interchange

26250
2735
80925
EH22640
MMHOSE-2.5

No data found.

The Coolant Hose is a reinforced silicone design with a 2.50" inner diameter and 4 plies, rated up to 75 psi and 350°F, engineered for reliable fluid transfer on Heavy Duty commercial vehicle applications. Meeting SAE J20 standards, the piece delivers consistent flexibility.
