Brake Rotor-Kit 16.14" Depth 2.09" Machined - 153.10041217
Part#: AAA53710041217
Features and Benefits
- Disc brake rotor product type for accurate identification during service
- Material of G3500 construction for the product body
- Depth of 2.09" for the product body dimension
- Disc outer diameter of 16.14" for correct brake rotor fitment
- Pilot diameter of 6.56" for correct hub centering fitment
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Description | Air Disc Rotor 410Mm 16.141In |
|---|---|
| Brake Style | Air Disc |
| Disc Outer Diameter | 16.14 in. |
| Depth | 2.09 in. |
| Pilot Diameter | 6.56 in. |
| Bolt Circle Diameter | 8.86 in. |
| Hole Diameter | 0.67 in. |
| Bolt Holes | 10.00 |
| ABS Tone Ring | Included |
| ABS Screws | Five 1/4 Inch |
| Nuts | Ten 5/8 Inch |
| Part Type | Disc Brake Rotor |
| Grade Type | Standard Replacement |
| ABS Tone Ring Included | Yes |
| Bearings Included | No |
| Brake Surface Finish | Machined |
| Brake System | Air Disc |
| Center Hole Diameter | 6.56 in. |
| Construction | Full Cast |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-Directional |
| Disc Finish | Machined |
| Discard Thickness | 1.46 in. |
| Floating | No |
| Material | G3500 |
| Maximum Brake Diameter Discard | 1.46 in. |
| Mounting Bolt Hole Circle Diameter | 7.86 in. |
| Mounting Bolt Hole Diameter | 0.66 in. |
| Mounting Bolt Hole Quantity | 10.00 |
| Nominal Thickness | 1.77 in. |
| Nonsaleable | No |
| Manufacturing Type | New Aftermarket |
| Wheel Size | 19.50 |
| Rotor Diameter | 16.14 in. |
| Interchange |
|---|
| 013001026 |
| 10041217 |
| 153.1004122 |
| 1531004122 |
| 22024043 |
| 55074PK |
| 7413-10041217 |
| CM 10041217 |
| CM10041217 |
| CNM10041217 |
| Year | Make | Model | Engine |
|---|---|---|---|
| MACK | |||
| VOLVO |
The Air Disc Rotor is 16.14" OD, 2.09" depth, 6.56" pilot, 8.86" bolt circle, 10-hole, with an ABS tone ring, engineered for reliable braking on Heavy Duty commercial vehicle applications. Designed as a direct replacement, the part delivers consistent performance and dependable results across a wide range of fleet configurations.
