Air Spring Rolling Lobe 9" Top x 2.01" Bottom Dia - 566.CT75561
Part#: AAA50175561
Features and Benefits
- Rolling lobe type for smooth, progressive suspension response across the operating range
- 1/4-18 NPTF air inlet thread for a reliable, leak-resistant pneumatic connection
- M12 x 1.75 mm top and bottom mounting studs for secure multi-point frame and axle attachment
- 1.65" top plate thickness with 2.75" center-to-center diameter for precise mounting alignment
- 5.52" bellows height for defined air spring stroke and consistent load support performance
- 23" extended height and 12.6" maximum diameter for maximum suspension travel and load coverage
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Extended Height | 23 in. |
|---|---|
| Compressed Height | 6.9 in. |
| Top Plate Diameter | 9 in. |
| Top Plate Thickness | 1.65 in. |
| Top Plate Center to Center Diameter | 2.75 in. |
| Bottom Plate Diameter | 10.04 in. |
| Bottom Plate Diameter | 2.01 in. |
| Maximum Diameter | 12.6 in. |
| Air Inlet Thread Size | 1/4-18 NPTF |
| Mounting Stud Thread Size (Top) | M12 x 1.75 mm |
| Mounting Stud Thread Size (Bottom) | M12 x 1.75 mm |
| Bellows Height | 5.52 in. |
| Type | Rolling Lobe |
| Interchange |
|---|
| 1R121049 |
| 1R12654 |
| 21132004 |
| 21132005 |
| 21244322 |
| 21669088 |
| 3451456 |
| 3528468 |
| 4528468 |
| 566.ER8468 |
| 75561 |
| 8468 |
| 910S17P1206 |
| AB1DF23HP1206 |
| AB1DK23KC395 |
| AMAB1DF23HP1206 |
| AS8468 |
| AS84680 |
| FS8468 |
| MPN1R12654 |
| STM1R12654 |
| W01M3588468 |
| W01M588468 |
The Air Spring Continental rolling lobe design provides reliable suspension performance with a 1/4-18 NPTF air inlet, ensuring a secure pneumatic connection for Heavy Duty commercial vehicle applications. Engineered for consistent load bearing across demanding trailer and chassis configurations.
