DPF Component 14.18" - 561.291418K2
Part#: AAA443291418K2
Features and Benefits
- Overall dimensions of 17" x 17" x 3.5" for the product package size
- Diameter of 14.18" for correct fitment engagement
- Sold as a kit
- V-insert angle of 42 deg for the clamp band profile
- V-insert depth of 0.29" for the clamp band profile
- V-insert groove dimension of 0.41" for the clamp band profile
Select Alternative Part #
Warranty
Up to 3 years warranty
Please contact customer service to know more details
| Bolt Size | 0.31 in. |
|---|---|
| Diameter | 14.18 in. |
| Dimensions | 17.00 in. x 17.00 in. x 3.50 in. |
| Sold as Kit | Yes |
| Torque Range | 170-200 in-lbs |
| V Insert Angle | 42° |
| V Insert Depth (C) | 0.29 in. |
| V Insert Groove (B) | 0.41 in. |
| V Insert Thickness (A) | 0.08 in. |
| V Insert Width (F) | 1.08 in. |
| Interchange |
|---|
| 561.291418 |
| 562.U851418 |
| 889626497087 |
No data found.
The DPF Component is a V-band clamp kit with a 14.18" diameter and 42° V insert angle, rated for 170-200 in-lbs torque, engineered for reliable exhaust connection on Heavy Duty commercial vehicle applications. The kit delivers consistent structural stability across configurations.
