Actuator 2.65" Top Plate Diameter 0.75"-16 UNC - ABSZ70-4187

Actuator 2.65" Top Plate Diameter 0.75"-16 UNC - ABSZ70-4187

Part#: AAA506ABSZ70-4187

Features and Benefits

Dock lock actuator / air spring product type for accurate identification during service
Outer diameter of 2.66" for correct fitment dimension
Top plate hole/stud quantity of 1 for the product specification
Bumper of no for the product specification

Warranty

Up to 3 years warranty

Please contact customer service to know more details

SPECIFICATIONS
INTERCHANGE
APPLICATION
DESCRIPTION

Type	Sleeve Type
Top Plate Hole/Stud Quantity	1.00
Top Plate Diameter. (A)	2.65
Bottom Plate Hole/Stud Quantity	1.00
Bottom Plate Diameter. (C)	2.65
Bumper	No
Min. Height	4.00
Max. Height	10.50
Top Plate Hole/Stud Count	(1) Hole/Stud
Top Plate Thread Size	0.75 in. - 16 UNC
Top Plate Port Size	0.12 in. - 27 NPTF
Top Plate Diameter	2.65 in.
Bottom Plate Thread Size	0.75 in. - 16 UNF-2A
Maximum Height	10.50 in.
Minimum Height	4.00 in.
Product Type	Dock Lock Actuator / Air Spring
Air Spring Type	Sleeve Type
Top Plate Width	2.65 in.
Piston Width	2.65 in.
Compressed Height	4.00 in.
Full Extension	10.50 In
Diameter	2.66 in.
Dust Tube	Included
Unit Of Measure	Each
Automann Number	Absz70-4187
Hendrickson Turner Number	S29899, Ssr1Va1031

Interchange

1S4-187
1S4187
334-2248
ABSZ704187
FXABSZ70-4187
MZHABSZ70-4187
S-29899
S-R1VA103-1
S-SR1VA103-1
S29899
SSR1VA1031

Year	Make	Model	Engine

	FREIGHTLINER	CASCADIA
	HENDRICKSON
	HENDRICKSON	TRAILER
	HENDRICKSON	TURNER TRAILERS
	INTERNATIONAL	LT
	KENWORTH	T680
	PETERBILT	579
	VOLVO	VNL

The Actuator is engineered for reliable control on Heavy Duty commercial vehicle applications. Designed as a direct replacement, the part delivers consistent performance and dependable results across a wide range of fleet configurations. The component meets OEM specification.
