Clevis Pin and Kit Standard 1.25" x 5" Medium Carbon Steel Plain - 1250-5000

Clevis Pin and Kit Standard 1.25" x 5" Medium Carbon Steel Plain - 1250-5000

Part#: AAA551-1250-5000

Features and Benefits

Hts number of 7318290000 ensures correct fit and reliable performance
Set of 5.00" length ensures proper fit and coverage for the intended application
Set of 4.38" length ensures proper fit and coverage for the intended application
Set of 1.25" diameter matches OEM specification for a leak-free, secure fit
.250" diameter matches OEM specification for a leak-free, secure fit
Inch or metric of inch ensures correct fit and reliable performance

Warranty

Up to 3 years warranty

Please contact customer service to know more details

SPECIFICATIONS
INTERCHANGE
APPLICATION
DESCRIPTION

Rohs Compliant	Yes
Hts Number	7318290000.00
Shank Length	5.00 in
Effective Length	4.38 in
Outside Diameter	1.25 in
Hole Diameter	.250 in
Inch Or Metric	Inch
Finish	Plain
Material	Medium Carbon Steel
Type	Clevis Pin Standard
Head Diameter	1.49 in
Head Height	.420 in
Head Diameter Maximum	1.50 in
Head Diameter Minimum	1.47 in
Head Height Maximum	.350 in
Head Height Minimum	.330 in
Hole Diameter Maximum	.260 in
Hole Diameter Minimum	.245 in
Outside Diameter Maximum	1.25 in
Outside Diameter Minimum	1.23 in
Shank Length Maximum	5.02 in
Shank Length Minimum	5.00 in
Effective Length Fraction	4.38 in
Hole Diameter Fraction	1/4 in
Outside Diameter Fraction	1.25 in
Shank Length Fraction	5.00 in
Outside Diameter Maximum Fraction	1.25 in
Head Diameter Maximum Fraction	1.50 in
Mating Part	Bp-208

No data found.

The CLEVIS PIN 1-1/4 X 5 is a heavy-duty clevis pin and kit engineered for commercial truck applications. With Yes Rohs Compliant, it ensures optimal performance in demanding fleet environments. It includes all required components for a complete, reliable service or repair procedure. Parts are matched for compatibility and engineered to restore original performance.
